LV Busducts

    • Air insulated, Non-segregated type
    • Busduct ratings of upto 4000A
    • Short Circuit rating of 50KA for 1 sec RMS
    • Also non-magnetic aluminium enclosures
    • Flexible Terminations
    • Flexible In-line Connections
Rising Mains
    • Air insulated, Non-segregated type Rising Mains
    • Indoor Vertical Erection type
    • Rising Main ratings of upto 1250A
    • Short Circuit rating of 50KA for 1 sec RMS
    • Fixed type Tap off Boxes
    • Flexible In-line Connections
    • Fire Barriers
    • Wall supports

We have type tested our Busduct / Raising mains for Short circuit withstand capacity of 50kA rms for 1 second at Central Power Research Institute, Bangalore, India.

Technical Specifications
Rated Service Voltage  415 V
Rated Frequency : 50hz
Busbar System :  Three Phase and Neutral
Rated Insulation Voltage : 660 V
Max.Rating Of Busbars : 4000 A  and higher
Fault Level Withstand : 50 kA rms for 1 second
